1~5 Color Mini Ribbon Screen Printing Machine,Fully Automatic Ribbon Screen Printer Machine,Fabric Satin Tape Belt Silk Screen Printing Equipment
|
|
| |
| |
Features: |
| |
- Manufacture and Wholesale 1~5 Color Mini Ribbon Screen Printing Machine, Fully Automatic Ribbon Screen Printer Machine, Fabric Satin Tape Belt Silk Screen Printing Equipment.
- The 1~5 Color Mini Ribbon Screen Printing Machine,Fully Automatic Ribbon Screen Printer Machine,Fabric Satin Tape Belt Silk Screen Printing Equipment can be constructed for single face or double faces color screen printing on various of fabric trademarks, ribbon, elastic band, fashion tape, heavy tape, cut pieces etc.
- Fully automatic multi color screen printing, auto winding & rewinding, auto screen printing and ink drying etc.
- Works with PLC Touch Screen and Servo Motor control system etc for high quality and precision screen printing.
- Can use any high temperature inks such as: foam, Plastisol ink, silica gel etc.
- Works with Steel belt for transmission, so the multi colors registration are accurate, no need to worry about the traditional PVC belt deformation.
- Printing times, speed and length etc are adjustable.
- Each color screen printing equips with independent ink drying system.
|
| |
Main Specifications: |
| |
Models |
PM-S150A3C |
PM-S150A5C |
Silk screen printing color |
1~3 colors |
1~5 colors |
Silk screen printing table size |
150x400mm |
Max silk screen flame size |
150x420mm |
Max each printing width and length |
120x350mm |
| Roll ribbons max printing width |
120mm |
Max silk screen printing speed |
25 Times/Min |
Work piece max thickness |
10mm |
Power supply |
3 phase 380V, 25AM, 7KW |
3 phase 380V, 25AM, 9KW |
Machine dimension |
3600x850x1600mm |
5600x850x1600mm |
Machine weight |
950kg |
1350kg |
|
| |
|
|
Video of 1~5 Color Mini Ribbon Screen Printing Machine,Fully Automatic Ribbon Screen Printer Machine,Fabric Satin Tape Belt Silk Screen Printing Equipment
|
|
