- Operating system: Windows98 / WindowsMe / WindowsXP / Windows7.
- Editing software: Powerful Kadex dedicated computer typesetting software, comes with video instruction.
- Software features: Free graphical and text editor, what you see is what you get.
- Users can either use the machine support software to make any complicate patterns or directly apply an itmap (BMP) format file that is made by other software.
- Since the machine software is already installed into your PC, you can use all existed fonts; or introduce the new fonts if you want.
- The screen displays all printing parameters.
- Printing precision: 200 DPI.
- Status display: Red (sensor normal), yellow (synchronizer normal), green (printing normal), white light (links to computer normal).
- Print font: High resolution printing with any font of your computer, it also sprays bitmap fonts (like dot).
- Print graphics: Can print a variety of trademark graphics, also foreign characters, numbers, letters, symbols, patterns and special signs etc.
- Print row number: Within the print height of 18mm, it can edit and print any number of rows.
- Print Barcode: Such as CodaBar /Code11/Code128/Code39/Code93/JAN/UCC /EAN128/EAN13 / EAN8 Inter leaved 2 of 5/ISBN/MAT25/MSI/ PLANET/PostNet/SSCC18/ UPCE/UPCA.
- Character height: You can choose the font height from 1mm-18mm.
- Ink jet nozzle width: 18mm.
- Ink jet optimum distance: Nozzle to the object is 5-10mm.
- Ink jet direction: adjustable, forward, backward, straight down; turn upside etc.
- Automatic ink jet prints: Date, time, batch number, class and serial number etc.
- Storage of information: Can store unlimited messages.
- Message length: Each message can be more than 1000 characters.
- Serial numbers: Adjustable 1 ~ 9 figures and variable.
- Printing speed: Max 35 m / min, the printing speed will not change even you increase number of rows.
- Ink colors: Black, red, blue, white, green, yellow, UV ink.
- Printing material: metal, plastic, wood, aluminum foil, cardboard boxes and other surface materials.
- Applications: Mobile phone displays, beverage bottle and cap, food packaging bags, case, steel doors, aluminum alloy Batteries, plastic pipe, steel, circuit boards, chips, bags, eggs, brake pads, cell phone case, carton, etc.
- Using ink: quick dry environmental ink or oil-based ink, no need the external compressed air and diluents.
- External interface: USB, synchronizer, electronic eye.
- Power supply: AC 110-220V.
- Power consumption: Less than 100W on average.
- Use environment: temperature 1 ℃ - 37 ℃; Humidity 30% -70%.
- Weight: 25KG.
- Optional accessories: synchronizer, fiber optic sensors (identified various colors), transmission belts, brackets and so on.
|
